Choose your product version
| Product description | Base (standard designation) | Nominal wattage | Nominal voltage | Nominal lamp life time | Nominal luminous flux | Claimed equiv. conventional lamp power | Beam angle | Dimmable |
|---|---|---|---|---|---|---|---|---|
| P MR11 20 36 ° 2.5 W/2700 K GU4 | GU4 | 2.5 W | 12 V | 15000 h | 184 lm | 20 W | 36 ° | No |
| Nominal wattage | 2.5 W |
| Construction wattage | 2.50 W |
| Nominal voltage | 12 V |
| Claimed equiv. conventional lamp power | 20 W |
| Nominal current | 310 mA |
| Type of current | AC |
| Inrush current | 18 A |
| Operating frequency | 50…60 Hz |
| Mains frequency | 50…60 Hz |
| Max. lamp number on MCB B10 A | 35 |
| Max. lamp number on MCB B16 A | 55 |
| Power factor λ | > 0.50 |
| Luminous intensity | 400 cd |
| Luminous flux | 184 lm |
| Nominal useful luminous flux 90° | 184 lm |
| Luminous efficacy | 73 lm/W |
| Lumen main.fact.at end of nom.life time | 0.70 |
| Light color (designation) | Warm White |
| Color temperature | 2700 K |
| Color rendering index Ra | ≥80 |
| Light color | 827 |
| Standard deviation of color matching | ≤6 sdcm |
| Rated peak intensity | 400 cd |
| Rated LLMF at 6,000 h | 0.80 |
| Flickering metric (Pst LM) | 1.0 |
| Stroboscope effect metric (SVM) | 0.4 |
| Beam angle | 36 ° |
| Warm-up time (60 %) | ‹ 0.50 s |
| Starting time | < 0.5 s |
| Overall length | 38.00 mm |
| Diameter | 35.00 mm |
| Maximum diameter | 35 mm |
| Product weight | 17.00 g |
| Ambient temperature range | -20…+40 °C |
| Maximum temperature at tc test point | 75 °C |
| Number of switching cycles | 100000 |
| Lumen maintenance at end of service lifetime | 0.70 |
| Rated lamp survival factor at 6,000 h | ≥ 0.90 |
| Base (standard designation) | GU4 |
| Mercury content | 0.0 mg |
| Mercury-free | Yes |
| Product remark | All technical parameters apply to the entire lamp, Due to the complex production process for light-emitting diodes, the typical values shown for the technical LED parameters are purely statistical values that do not necessarily match the actual technical parameters of each individual product, which can vary from the typical value |
| Dimmable | No |
| Energy efficiency class | F 1) |
| Energy consumption | 3.00 kWh/1000h |
| Type of protection | IP20 |
| Standards | CE, CB, EAC |
| Photobiological safety group acc. to EN62778 | RG0 |
1) Energy efficiency class (EEC) on a scale of A++ (highest efficiency) to E (lowest efficiency)
| Order reference | LEDPMR112036 2, |
| Light source cap-type (or other electric interface) | GU4 |
| Correlated colour temperature type | SINGLE_VALUE |
| Length | 38.00 mm |
| Height | 35.00 mm |
| Width | 35.00 mm |
| EPREL ID | 1402916 |
| Model number | AC08769 |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075105195 | Folding box 1 |
36 mm x 36 mm x 46 mm | 22.00 g | 0.06 dm³ |
| 4058075105201 | Shipping box 10 |
188 mm x 78 mm x 55 mm | 269.00 g | 0.81 dm³ |
| 4058075131842 | Shipping box 80 |
201 mm x 169 mm x 240 mm | 2168.00 g | 8.15 dm³ |
| EAN | SEG number | EFO number | ELDAS number |
|---|---|---|---|
| 4058075105195 | 8293987 | 3719980 | 941800890 |
