OVERVIEW

Product description	Base (standard designation)	Nominal wattage	Nominal voltage	Nominal lamp life time	Nominal luminous flux	Dimmable
DULUX L 18 W/827 2G11	2G11	18 W	58 V	20000 h	1175 lm	Yes
DULUX L 18 W/830 2G11	2G11	18 W	58 V	20000 h	1175 lm	Yes
DULUX L 18 W/840 2G11	2G11	18 W	58 V	20000 h	1175 lm	Yes
DULUX L 24 W/827 2G11	2G11	24 W	87 V	20000 h	1620 lm	Yes
DULUX L 24 W/830 2G11	2G11	24 W	87 V	20000 h	1620 lm	Yes
DULUX L 24 W/840 2G11	2G11	24 W	87 V	20000 h	1620 lm	Yes
DULUX L 36 W/865 2G11	2G11	36 W	220 V	8000 h
DULUX L 36 W/840 2G11	2G11	36 W	220 V	8000 h
DULUX L 36 W/865 2G11	2G11	36 W	106 V	20000 h	2500 lm	Yes
DULUX L 36 W/827 2G11	2G11	36 W	106 V	20000 h	2600 lm	Yes
DULUX L 36 W/830 2G11	2G11	36 W	106 V	20000 h	2600 lm	Yes
DULUX L 36 W/840 2G11	2G11	36 W	106 V	20000 h	2600 lm	Yes
DULUX L 40 W/865 2G11	2G11	40 W	126 V	20000 h	3000 lm	Yes
DULUX L 40 W/830 2G11	2G11	40 W	126 V	20000 h	3150 lm	Yes
DULUX L 40 W/840 2G11	2G11	40 W	126 V	20000 h	3150 lm	Yes
DULUX L 55 W/830 2G11	2G11	55 W	101 V	12000 h
DULUX L 55 W/865 2G11	2G11	55 W	101 V	20000 h	4100 lm	Yes
DULUX L 55 W/827 2G11	2G11	55 W	101 V	20000 h	4320 lm	Yes
DULUX L 55 W/830 2G11	2G11	55 W	101 V	20000 h	4320 lm	Yes
DULUX L 55 W/840 2G11	2G11	55 W	101 V	20000 h	4320 lm	Yes
DULUX L 80 W/830 2G11	2G11	80 W	145 V	20000 h	5600 lm	Yes
DULUX L 80 W/840 2G11	2G11	80 W	145 V	20000 h	5600 lm	Yes

DULUX L 80 W/840 2G11

Product benefits

Less than half as long as tubular fluorescent lamps

View all details

Product data sheet

PRODUCT DETAILS

Technical data

Electrical data

Nominal wattage	80 W
Construction wattage	82.00 W
Nominal voltage	145 V
Nominal current	0.56 A

Photometrical data

Luminous flux	5600 lm
Luminous efficacy	68 lm/W
Light color (designation)	LUMILUX Cool White
Color temperature	4000 K
Color rendering index Ra	≥80
Light color	840
Rated LLMF at 2,000 h	0.94
Rated LLMF at 4,000 h	0.90
Rated LLMF at 6,000 h	0.88
Rated LLMF at 8,000 h	0.85
Rated LLMF at 12,000 h	0.84
Rated LLMF at 16,000 h	0.81
Rated LLMF at 20,000 h	0.80

Dimensions & Weight

Overall length	565.00 mm
Length with base excl. base pins/connection	565,00 mm
Diameter	17,5 mm
Tube diameter	17,5 mm
Product weight	122.00 g

Temperatures & operating conditions

Ambient temperature range

-5…+40 °C

Lifespan

Service life	13000 h ¹⁾
Rated lamp survival factor at 2,000 h	0.99
Rated lamp survival factor at 4,000 h	0.99
Rated lamp survival factor at 6,000 h	0.99
Rated lamp survival factor at 8,000 h	0.99
Rated lamp survival factor at 12,000 h	0.95
Rated lamp survival factor at 16,000	0.81
Rated lamp survival factor at 20,000 h	0.50
Lifespan B50	20000 h

¹⁾ With preheat ECG

Additional product data

Base (standard designation)	2G11
Mercury content	5.0 mg
Product remark	For ECG operation only

Capabilities

Dimmable

Yes

Certificates & Standards

Energy efficiency class	G
Energy consumption	83.00 kWh/1000h

Country-specific categorizations

ILCOS	FSDH-80/840-/P/-2G11-43,9/565
Order reference	DULUX L 80W/840

Energy labelling regulation data acc EU 2019/2015

Lighting technology used	CFLNI
Non-directional or directional	NDLS
Mains or non-mains	NMLS
Light source cap-type (or other electric interface)	2G11
Connected light source (CLS)	No
Color-tuneable light source	No
Envelope	No
High luminance light source	No
Anti-glare shield	No
Correlated colour temperature type	SINGLE_VALUE
Claim of equivalent power	No
Length	565.00 mm
Height	17,5 mm
Width	17,5 mm
Chromaticity coordinate x	0,380
Chromaticity coordinate y	0,380
Beam angle correspondence	SPHERE_360
EPREL ID	546523
Model number	AC34297

PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS

Quantity of precious metals	0 mg
Quantity of rare earths	0 mg
Minimum rate of recycled material in packaging	80 % ¹⁾
Minimum percentage of recycled content in the product	0 % ¹⁾
Product recyclability	Mostly recyclable product ¹⁾
Packaging recyclability	Mostly recyclable packaging ¹⁾
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage	No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage	No

¹⁾ According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)

Product description

Product benefits

Less than half as long as tubular fluorescent lamps

Areas of application

Offices, public buildings
Shops
Supermarkets and department stores
Hotels, restaurants
Industry

Product features

Short and compact pin-base lamp with double-turn tubes
Single-ended four-pin plug-in 2G11 base
Dimmable (1…100 % with QUICKTRONIC® QTi DALI/DIM)
Good color rendering index

Equipment / Accessories

Suitable for standard control gears and starters
Suitable for operation on electronic and conventional control gear

Safety advice

In case of lamp breakage: www.ledvance.com/brokenlamp

References / Links

For more information on the system guarantee and the terms and conditions of the guarantee visit www.ledvance.com/system-guarantee

GTIN and Packaging information

Product code	Packaging unit (Pieces/Unit)	Dimensions (length x width x height)	Gross weight	Volume
4050300665481	Folding box 1	26 mm x 46 mm x 598 mm	190.00 g	0.72 dm³
4050300665498	Shipping box 10	617 mm x 140 mm x 107 mm	2060.00 g	9.24 dm³

Country-specific information

EAN	SEG number	STK number	EFO number	ELDAS number
4050300665481	8330480	4934140	3860440	946168410

18 W/827 2G11

18 W/830 2G11

18 W/840 2G11

24 W/827 2G11

24 W/830 2G11

24 W/840 2G11

36 W/865 2G11

36 W/840 2G11

36 W/865 2G11

36 W/827 2G11

36 W/830 2G11

36 W/840 2G11

40 W/865 2G11

40 W/830 2G11

40 W/840 2G11

55 W/830 2G11

55 W/865 2G11

55 W/827 2G11

55 W/830 2G11

55 W/840 2G11

80 W/830 2G11

80 W/840 2G11
