Choose your product version
| Product description | Base (standard designation) | Nominal wattage | Nominal voltage | Nominal lamp life time | Nominal luminous flux | Dimmable |
|---|---|---|---|---|---|---|
| L 18 W/940 | G13 | 18 W | 57 V | 20000 h | 1200 lm | Yes |
| L 18 W/954 | G13 | 18 W | 57 V | 20000 h | 1150 lm | Yes |
| L 36 W/930 | G13 | 36 W | 103 V | 20000 h | 2700 lm | Yes |
| L 36 W/940 | G13 | 36 W | 103 V | 20000 h | 2900 lm | Yes |
| L 36 W/954 | G13 | 36 W | 103 V | 20000 h | 2850 lm | Yes |
| Nominal wattage | 36 W |
| Construction wattage | 38.00 W |
| Nominal voltage | 103 V |
| Nominal current | 0.43 A |
| Luminous flux | 2850 lm |
| Luminous efficacy | 75 lm/W |
| Light color (designation) | LUMILUX DE LUXE Daylight |
| Color temperature | 5400 K |
| Color rendering index Ra | ≥90 |
| Light color | 954 |
| Rated LLMF at 2,000 h | 0.96 |
| Rated LLMF at 4,000 h | 0.94 |
| Rated LLMF at 6,000 h | 0.93 |
| Rated LLMF at 8,000 h | 0.91 |
| Rated LLMF at 12,000 h | 0.91 |
| Rated LLMF at 16,000 h | 0.90 |
| Rated LLMF at 20,000 h | 0.89 |
| Overall length | 1213.60 mm |
| Length with base excl. base pins/connection | 1200 mm |
| Diameter | 26.00 mm |
| Tube diameter | 26 mm |
| Product weight | 165.00 g |
| Service life | 16000 h 1) |
| Rated lamp survival factor at 2,000 h | 0.99 |
| Rated lamp survival factor at 4,000 h | 0.99 |
| Rated lamp survival factor at 6,000 h | 0.99 |
| Rated lamp survival factor at 8,000 h | 0.99 |
| Rated lamp survival factor at 12,000 h | 0.99 |
| Rated lamp survival factor at 16,000 | 0.90 |
| Rated lamp survival factor at 20,000 h | 0.50 |
| Lifespan B50 | 20000 h |
1) With preheat ECG
| Base (standard designation) | G13 |
| Mercury content | 3.0 mg |
| Dimmable | Yes |
| Energy efficiency class | G |
| Energy consumption | 38.00 kWh/1000h |
| ILCOS | FD-36/954-E-G13-26/1200 |
| Order reference | L 36W/954 |
| Lighting technology used | OTHER_FL |
| Non-directional or directional | NDLS |
| Mains or non-mains | NMLS |
| Light source cap-type (or other electric interface) | G13 |
| Connected light source (CLS) | No |
| Color-tuneable light source | No |
| Envelope | No |
| High luminance light source | No |
| Anti-glare shield | No |
| Correlated colour temperature type | SINGLE_VALUE |
| Claim of equivalent power | No |
| Length | 1213.60 mm |
| Height | 26.00 mm |
| Width | 26.00 mm |
| Chromaticity coordinate x | 0,335 |
| Chromaticity coordinate y | 0,350 |
| Beam angle correspondence | SPHERE_360 |
| EPREL ID | 546391 |
| Model number | AC34166 |
| Quantity of precious metals | 0 mg |
| Quantity of rare earths | 0 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | Additional info can be provided per individual request |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4050300018263 | Sleeve 1 |
1,215 mm x 27 mm x 27 mm | 171.80 g | 0.89 dm³ |
| 4050300246796 | Shipping box 25 |
1,253 mm x 151 mm x 153 mm | 4870.00 g | 28.95 dm³ |
| EAN | SEG number | STK number | EFO number | ELDAS number |
|---|---|---|---|---|
| 4050300018263 | 8329286 | 4930452 | 3820373 | 946105290 |
