Choose your product version
| Product description | Base (standard designation) | Nominal wattage | Nominal lamp life time | Nominal luminous flux | Dimmable | |
|---|---|---|---|---|---|---|
| HE 14 W/827 | G5 | 14 W | 86 V | 24000 h | 1350 lm | Yes |
| HE 14 W/830 | G5 | 14 W | 86 V | 24000 h | 1350 lm | Yes |
| HE 14 W/830 | G5 | 14 W | 86 V | 24000 h | 1350 lm | Yes |
| HE 14 W/840 | G5 | 14 W | 86 V | 24000 h | 1350 lm | Yes |
| HE 14 W/865 | G5 | 14 W | 220 V | 24000 h | 1100 lm | |
| HE 14 W/865 | G5 | 14 W | 86 V | 24000 h | 1300 lm | Yes |
| HE 14 W/865 | G5 | 14 W | 86 V | 24000 h | 1300 lm | Yes |
| HE 21 W/827 | G5 | 21 W | 126 V | 24000 h | 2000 lm | Yes |
| HE 21 W/830 | G5 | 21 W | 126 V | 24000 h | 2000 lm | Yes |
| HE 21 W/830 | G5 | 21 W | 126 V | 24000 h | 2000 lm | Yes |
| HE 21 W/840 | G5 | 21 W | 126 V | 24000 h | 2000 lm | Yes |
| HE 21 W/865 | G5 | 21 W | 126 V | 24000 h | 1925 lm | Yes |
| HE 28 W/827 | G5 | 28 W | 166 V | 24000 h | 2800 lm | Yes |
| HE 28 W/830 | G5 | 28 W | 166 V | 24000 h | 2800 lm | Yes |
| HE 28 W/840 | G5 | 28 W | 220 V | 24000 h | 2600 lm | |
| HE 28 W/840 | G5 | 28 W | 166 V | 24000 h | 2800 lm | Yes |
| HE 28 W/865 | G5 | 28 W | 220 V | 24000 h | 2400 lm | Yes |
| HE 28 W/865 | G5 | 28 W | 220 V | 24000 h | 2400 lm | |
| HE 28 W/865 | G5 | 28 W | 166 V | 24000 h | 2700 lm | Yes |
| HE 35 W/827 | G5 | 35 W | 220 V | 24000 h | 3550 lm | Yes |
| HE 35 W/830 | G5 | 35 W | 220 V | 24000 h | 3550 lm | Yes |
| HE 35 W/840 | G5 | 35 W | 220 V | 24000 h | 3320 lm | |
| HE 35 W/840 | G5 | 35 W | 220 V | 24000 h | 3550 lm | Yes |
| HE 35 W/865 | G5 | 35 W | 24000 h | 3050 lm | Yes | |
| HE 35 W/865 | G5 | 35 W | 220 V | 24000 h | 3400 lm | Yes |
| Nominal wattage | 21 W |
| Construction wattage | 20.70 W |
| Nominal voltage | 126 V |
| Nominal current | 0.17 A |
| Luminous flux | 2000 lm |
| Luminous efficacy | 97 lm/W |
| Luminous flux at 35 °C | 2000 lm |
| Light color (designation) | LUMILUX Cool White |
| Color temperature | 4000 K |
| Color rendering index Ra | ≥80 |
| Light color | 840 |
| Rated LLMF at 2,000 h | 0.95 |
| Rated LLMF at 4,000 h | 0.92 |
| Rated LLMF at 6,000 h | 0.91 |
| Rated LLMF at 8,000 h | 0.90 |
| Rated LLMF at 12,000 h | 0.90 |
| Rated LLMF at 16,000 h | 0.90 |
| Rated LLMF at 20,000 h | 0.89 |
| Overall length | 863.20 mm |
| Length with base excl. base pins/connection | 849,00 mm |
| Diameter | 16,0 mm |
| Tube diameter | 16 mm |
| Product weight | 70.92 g |
| Service life | 19000 h 1) |
| Rated lamp survival factor at 2,000 h | 0.99 |
| Rated lamp survival factor at 4,000 h | 0.99 |
| Rated lamp survival factor at 6,000 h | 0.99 |
| Rated lamp survival factor at 8,000 h | 0.99 |
| Rated lamp survival factor at 12,000 h | 0.99 |
| Rated lamp survival factor at 16,000 | 0.97 |
| Rated lamp survival factor at 20,000 h | 0.85 |
| Lifespan B50 | 24000 h |
1) With preheat ECG
| Base (standard designation) | G5 |
| Mercury content | 1.5 mg |
| Product remark | Suitable for ECG operation only, Lamp designed for internal luminaire temperatures of 30…40 °C; optimum luminous flux achieved at 35 °C |
| Dimmable | Yes |
| Energy efficiency class | F |
| Energy consumption | 21.00 kWh/1000h |
| ILCOS | FDH-21/840-L/P/-G5-16/849 |
| Order reference | HE 21W/840 |
| Lighting technology used | LFL_T5_HE |
| Non-directional or directional | NDLS |
| Mains or non-mains | NMLS |
| Light source cap-type (or other electric interface) | G5 |
| Connected light source (CLS) | No |
| Color-tuneable light source | No |
| Envelope | No |
| High luminance light source | No |
| Anti-glare shield | No |
| Correlated colour temperature type | SINGLE_VALUE |
| Claim of equivalent power | No |
| Length | 863.20 mm |
| Height | 16,0 mm |
| Width | 16,0 mm |
| Chromaticity coordinate x | 0,380 |
| Chromaticity coordinate y | 0,380 |
| Beam angle correspondence | SPHERE_360 |
| EPREL ID | 546267 |
| Quantity of precious metals | 0 mg |
| Quantity of rare earths | 0 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | Additional info can be provided per individual request |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4050300591407 | Sleeve 1 |
18 mm x 18 mm x 863 mm | 80.86 g | 0.28 dm³ |
| 4050300464701 | Unpacked 1 |
863 mm x 16 mm x 16 mm | 81.63 g | 0.22 dm³ |
| 4050300591414 | Shipping box 20 |
891 mm x 104 mm x 88 mm | 2134.00 g | 8.16 dm³ |
| 4050300464718 | Shipping box 40 |
896 mm x 199 mm x 87 mm | 2968.00 g | 15.51 dm³ |
| EAN | SEG number | STK number | EFO number | ELDAS number |
|---|---|---|---|---|
| 4050300591407 | 8328528 | 4932321 | 3820173 | 946134120 |
